FalconHound – A Blue Team Multi-Tool. It Allows You To Utilize And Enhance The Power Of Blo odHound In A More Automated Fashion

FalconHound is a blue team multi-tool. It allows you to utilize and enhance the power of BloodHound in a more automated fashion. It is designed to be used in conjunction with a SIEM or other log aggregation tool.

One of the challenging aspects of BloodHound is that it is a snapshot in time. FalconHound includes functionality that can be used to keep a graph of your environment up-to-date. This allows you to see your environment as it is NOW. This is especially useful for environments that are constantly changing.

One of the hardest releationships to gather for BloodHound is the local group memberships and the session information. As blue teamers we have this information readily available in our logs. FalconHound can be used to gather this information and add it to the graph, allowing it to be used by BloodHound.

This is just an example of how FalconHound can be used. It can be used to gather any information that you have in your logs or security tools and add it to the BloodHound graph.

Additionally, the graph can be used to trigger alerts or generate enrichment lists. For example, if a user is added to a certain group, FalconHound can be used to query the graph database for the shortest path to a sensitive or high-privilege group. If there is a path, this can be logged to the SIEM or used to trigger an alert.

Other examples where FalconHound can be used:

• Adding, removing or timing out sessions in the graph, based on logon and logoff events.
• Marking users and computers as compromised in the graph when they have an incident in Sentinel or MDE.
• Adding CVE information and whether there is a public exploit available to the graph.
• All kinds of Azure activities.
• Recalculating the shortest path to sensitive groups when a user is added to a group or has a new role.
• Adding new users, groups and computers to the graph.
• Generating enrichment lists for Sentinel and Splunk of, for example, Kerberoastable users or users with ownerships of certain entities.

The possibilities are endless here. Please add more ideas to the issue tracker or submit a PR.

A blog detailing more on why we developed it and some use case examples can be found here

Index:

• Supported data sources and targets
• Installation
• Usage
• Actions
• Extensions to the graph
• Credential Management
• Deployment
• License

Supported data sources and targets

FalconHound is designed to be used with BloodHound. It is not a replacement for BloodHound. It is designed to leverage the power of BloodHound and all other data platforms it supports in an automated fashion.

Currently, FalconHound supports the following data sources and or targets:

• Azure Sentinel
• Azure Sentinel Watchlists
• Splunk
• Microsoft Defender for Endpoint
• Neo4j
• MS Graph API (early stage)
• CSV files

Additional data sources and targets are planned for the future.

At this moment, FalconHound only supports the Neo4j database for BloodHound. Support for the API of BH CE and BHE is under active development.

Installation

Since FalconHound is written in Go, there is no installation required. Just download the binary from the release section and run it. There are compiled binaries available for Windows, Linux and MacOS. You can find them in the releases section.

Before you can run it, you need to create a config file. You can find an example config file in the root folder. Instructions on how to creat all crededentials can be found here.

The recommened way to run FalconHound is to run it as a scheduled task or cron job. This will allow you to run it on a regular basis and keep your graph, alerts and enrichments up-to-date.

Requirements

• BloodHound, or at least the Neo4j database for now.
• A SIEM or other log aggregation tool. Currently, Azure Sentinel and Splunk are supported.
• Credentials for each endpoint you want to talk to, with the required permissions.

Configuration

FalconHound is configured using a YAML file. You can find an example config file in the root folder. Each section of the config file is explained below.

Usage

Default run

To run FalconHound, just run the binary and add the -go parameter to have it run all queries in the actions folder.

./falconhound -go

List all enabled actions

To list all enabled actions, use the -actionlist parameter. This will list all actions that are enabled in the config files in the actions folder. This should be used in combination with the -go parameter.

./falconhound -actionlist -go

Run with a select set of actions

To run a select set of actions, use the -ids parameter, followed by one or a list of comma-separated action IDs. This will run the actions that are specified in the parameter, which can be very handy when testing, troubleshooting or when you require specific, more frequent updates. This should be used in combination with the -go parameter.

./falconhound -ids action1,action2,action3 -go

Run with a different config file

By default, FalconHound will look for a config file in the current directory. You can also specify a config file using the -config flag. This can allow you to run multiple instances of FalconHound with different configurations, against different environments.

./falconhound -go -config /path/to/config.yml

Run with a different actions folder

By default, FalconHound will look for the actions folder in the current directory. You can also specify a different folder using the -actions-dir flag. This makes testing and troubleshooting easier, but also allows you to run multiple instances of FalconHound with different configurations, against different environments, or at different time intervals.

./falconhound -go -actions-dir /path/to/actions

Run with credentials from a keyvault

By default, FalconHound will use the credentials in the config.yml (or a custom loaded one). By setting the -keyvault flag FalconHound will get the keyvault from the config and retrieve all secrets from there. Should there be items missing in the keyvault it will fall back to the config file.

./falconhound -go -keyvault

Actions

Actions are the core of FalconHound. They are the queries that FalconHound will run. They are written in the native language of the source and target and are stored in the actions folder. Each action is a separate file and is stored in the directory of the source of the information, the query target. The filename is used as the name of the action.

Action folder structure

The action folder is divided into sub-directories per query source. All folders will be processed recursively and all YAML files will be executed in alphabetical order.

The Neo4j actions should be processed last, since their output relies on other data sources to have updated the graph database first, to get the most up-to-date results.

Action files

All files are YAML files. The YAML file contains the query, some metadata and the target(s) of the queried information.

There is a template file available in the root folder. You can use this to create your own actions. Have a look at the actions in the actions folder for more examples.

While most items will be fairly self explanatory,there are some important things to note about actions:

Enabled

As the name implies, this is used to enable or disable an action. If this is set to false, the action will not be run.

Enabled: true

Debug

This is used to enable or disable debug mode for an action. If this is set to true, the action will be run in debug mode. This will output the results of the query to the console. This is useful for testing and troubleshooting, but is not recommended to be used in production. It will slow down the processing of the action depending on the number of results.

Debug: false

Query

The Query field is the query that will be run against the source. This can be a KQL query, a SPL query or a Cypher query depending on your SourcePlatform. IMPORTANT: Try to keep the query as exact as possible and only return the fields that you need. This will make the processing of the results faster and more efficient.

Additionally, when running Cypher queries, make sure to RETURN a JSON object as the result, otherwise processing will fail. For example, this will return the Name, Count, Role and Owners of the Azure Subscriptions:

MATCH p = (n)-[r:AZOwns|AZUserAccessAdministrator]->(g:AZSubscription)
  RETURN {Name:g.name , Count:COUNT(g.name), Role:type(r), Owners:COLLECT(n.name)}

Targets

Each target has several options that can be configured. Depending on the target, some might require more configuration than others. All targets have the Name and Enabled fields. The Name field is used to identify the target. The Enabled field is used to enable or disable the target. If this is set to false, the target will be ignored.

CSV

  - Name: CSV
    Enabled: true
    Path: path/to/filename.csv

Neo4j

The Neo4j target will write the results of the query to a Neo4j database. This output is per line and therefore it requires some additional configuration. Since we can transfer all sorts of data in all directions, FalconHound needs to understand what to do with the data. This is done by using replacement variables in the first line of your Cypher queries. These are passed to Neo4j as parameters and can be used in the query. The ReplacementFields fields are configured below.

  - Name: Sentinel
    Enabled: true

 - Name: Watchlist
    Enabled: true
    WatchlistName: FH_MDE_Exploitable_Machines
    DisplayName: MDE Exploitable Machines
    SearchKey: DeviceName
    Overwrite: true

  - Name: Splunk
    Enabled: true

  - Name: ADX
    Enabled: true
    Table: "name"

{
  "till": "2021-08-31T14:00:00Z",
  "source": "falconhound",
  "reason": "logoff",
}

SentinelAppSecret
SentinelAppID
SentinelTenantID
SentinelTargetTable
SentinelResourceGroup
SentinelSharedKey
SentinelSubscriptionID
SentinelWorkspaceID
SentinelWorkspaceName
MDETenantID
MDEAppID
MDEAppSecret
Neo4jUri
Neo4jUsername
Neo4jPassword
GraphTenantID
GraphAppID
GraphAppSecret
AdxTenantID
AdxAppID
AdxAppSecret
AdxClusterURL
AdxDatabase
SplunkUrl
SplunkApiToken
SplunkIndex
SplunkApiPort
SplunkHecToken
SplunkHecPort
BHUrl
BHTokenID
BHTokenKey
LogScaleUrl
LogScaleToken
LogScaleRepository
